Deye 20Kw Three Phase Hybrid Inverter Hv High Voltage (DEMO UNIT)

Deye 20Kw Three Phase Hybrid Inverter

DEMO UNIT , NEVER BEEN USED ONLY MOUNTED. INCLUDES ALL ACESSORIES AND ORIGINAL PACKAGING.

Description

Product Features:

• 100% unbalanced output, each phase
• AC couple to retrofit existing solar system
• *Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
• Max. charging/discharging current of 50A
• High voltage battery, higher efficiency
• 6 time periods for battery charging/discharging
• Support storing energy from diesel generator

Specifications:

• Battery Input Data:
• Battery Type: Lead-acid or Lithium-ion
• Battery Voltage Range (V): 160~700
• Max. Charging Current (A): 37
• Max. Discharging Current (A): 37
• Number of Battery Input: 1
• PV String Input Data:

• Max. DC Input Power (W): 26000
• Max. DC Input Voltage (V): 1000
• Start-up Voltage (V): 180
• MPPT Voltage Range (V): 150-850
• Max. Operating PV Input Current (A): 26+26+26
• No. of MPP Trackers/ No. of Strings per MPP Tracker: 2/2+2
• AC Input/Output Data:
• Rated AC Input/Output Active Power (W): 20000
• Max. AC Input/Output Apparent Power (VA): 22000
• Rated AC Input/Output Current (A): 30.4/29
• Max. AC Input/Output Current (A): 33.4/31.9
• Max. Continuous AC Passthrough (grid to load) (A): 35
• General

• Noise (dB): <55
• Ingress Protection(IP) Rating: IP65
• Cabinet Size (WxHxD mm): 408×638×237 (Excluding Connectors and Brackets)
• Weight (kg)" 30.5
